The LC No. C-51 is located on the Bhatinda - Hanumangarh - Bikaner Railway line on the road from Sangaria town/Railway station to Hanumangarh, SH-7. Government of Rajasthan had decided construction of Two lane ROB under Urban Development and Housing Department (UDH).
SALIENT FEATURES OF THE ROB:
|
S. No. |
Description |
Remarks |
|
1. |
LC No. |
51-C |
|
2. |
Location |
Railway between TP No. 66/10-11 |
|
3. |
Name of Railway Block Section |
Sangaria – Hanumangarh section of NWR |
|
4. |
Tehsil / District |
Sangaria / Hanumangarh |
|
5. |
ROB Length |
706.72 m (Ch. 163.58 to 870.28) |
|
6. |
Total no. of span |
16 Nos. |
|
7. |
Railway span arrangement |
1 x 33.428 m (SK) / 21670 (SQ) |
|
8. |
Viaducts span arrangement |
6x18.6 m & 1x13.57 m (Sangaria city side) 7x18.6 m & 1x13.60 m (Hanumangarh side) |
|
9. |
Length of RE/Retaining wall |
225.28 m (Sangaria city side) 180.2 m (Hanumangarh side) |
|
10. |
Skew Angle |
49.59º |
|
11 |
Approach Gradients |
1 in 30 |
